2022-11-17 20:24:04   213

RK3568四核64位Cortex-A55 处理器,采用全新ARM v8.2-A架构,主频最高可达2.0GHz,效能有大幅提升;采用22nm先进工艺,具有低功耗高性能的特点


Ruixin micro rk3568 chip is a general-purpose SOC positioned at the middle and high end. It adopts a 22nm process technology, integrates a 4-core arm architecture A55 processor and a Mali G52 2ee graphics processor, and supports 4K decoding and 1080p encoding. Rk3568 supports SATA / PCIe / USB3.0 and other types of peripheral interfaces, with independent NPU built in, which can be used in lightweight AI applications. Rk3568 supports Android 11 and Linux systems, and is mainly targeted at the customized markets of the Internet of things gateway, NVR storage, industrial control panel, industrial testing, industrial control box, karaoke, cloud terminal, vehicle central control and other industries.


图片关键词

图片关键词




图片关键词

Rk3568 follows the update and iteration of arm architecture, adopts A55 architecture and G52 graphics processor to continuously improve product performance, and adopts 22nm advanced technology to effectively improve energy consumption performance. Rk3568 has excellent compatibility with DDR particles. Support LP4 / lp4x / LP3 / DDR4 / DDR3, maximum frequency 1600MHZ, maximum capacity 8GB DDR3 and DDR4 support 2-chip selection mode, maximum capacity 8GB DDR3 and DDR4 ECC.

Rk3568 has rich function expansion interfaces, which can effectively improve the expansibility of industry customization. Rk3568 supports pcie3.0 1 × 2 / 2x1lanes, supporting pcie2.1 1x1lane, meeting 4G / 5G, WiFi 6, multiple network ports, NPU and other expansion requirements. Rk3568 supports 3x sata3.0 and solves various unstable problems of traditional AP processor USB extended SATA. It supports up to 4 USB ports, 1xusb3.0/usb2.0 host + 1xusb3.0/usb2.0 OTG + 1xusb2.0 host + 1xusb2.0 host. It supports dual Gigabit Ethernet ports and qsgmii to reduce IO port occupation and meet the multi network port requirements of industrial control and Internet of things gateway.

Integrated GPU, Vpu and NPU coprocessor

It integrates dual core architecture GPU, high-performance Vpu and high-performance NPU. GPU supports OpenGL es3.2/2.0/1.1 and vulkan1.1; Vpu can realize 4K 60fps h.265/h 264 / VP9 video decoding and 1080p 100fps h.265/h.264 video coding; NPU supports one click switching of mainstream architecture models such as Caffe / tensorflow

Rk3568 specification parameter configuration:

CPUQuad-core ARM Cortex-A55, Neon and FPU
GPUG52 2EE,

OpenGL ES1.1/2.0/3.0/3.1/3.2, Vulkan 1.1, OpenCL 2.0

NNIPRK NN, 0.8Tops
DDR32-bit DDR4/DDR3L/LP4/LP4x, ECC
EMMCNor SFC, spi NAND, eMMC 5.1
视频解码器4Kp60 H.264/H.265/VP9
视频编码器1080P60 H.264/H.265
ISP8M ISP, HDR
mipi_CSIMIPI-CSI2, 1×4-lane/2×2-lane@2.5Gbps/lane
DVP/CIFIO:150MHz,support BT.656/601/1120
显示RGB, LVDS/MIPI DSI, HDMI, eDp, Eink
SDIOSDIO 3.0 x3
外围设备USB 2.0 HOST, USB2.0 OTG
USB3.0 OTG, USB3.0 HOT, SATA3.0 x3, PCIE2.1 1x1Lane, QSGMII x1,

Combo with 3 Serdes Lanes

PCIE3.0, 1×2-Lanes/2×1-Lane@8Gbps
UART:10, SPI:4, PWM:16, I2C:6 , CAN FD:3, SAR-ADC:8
以太网GMACx2(10/100/1000M)
音频接口1x 8chI2S/TDM, 2x2ch I2S
8ch PDM
SPDIF OUT
OTPOTP (Size 8K)
密码国密(SM3/4), TEE, Trustzone
